5 Need-To-Know Frequency Areas of the Vocal

vocal-eq

EQ’ing a vocal track can be frustrating. Sometimes it seems to sound like it was stuck on later, and doesn’t flow with the rest of the track.

Below are the five frequency ranges you can start with when you are in trouble and need to figure out how to equalize your vocal so that it sits better with your song.

It goes without saying that no amount of EQ’ing is going to fix a badly recorded vocal. So be sure to have a clean and well-recorded vocal before you start mixing it.

1. The Too Low-Range

Usually, vocals can be filtered quite severely in the lowest range. Flip on the low-cut filter on the microphone when you’re recording to cut out the low-end rumble. Usually, this cuts at 75 or so but during mixing, you can filter it out even more.

Obviously, this depends on the singer’s voice but I usually go for a little over 100 Hz. Listening is critical here because you don’t want to cut out the singer’s character, especially if he has a good presence there in the lower register. For female singers, you can go even higher. But be careful of Barry White and Leonard Cohen type singers, they may need that extra rumble in their voice.

2. The Thick 150 Hz

For rounding out a vocal and making it more thick and full I would search around the 150 Hz area. Some singers sound thin and nasally and can do with a little meat on their vocal chords. Boosting here can give the vocal more punch.

3. Honky-Boxy 4-500 Hz

If your vocal track lacks definition and sounds boxy you can sweep around this area, even going so far as up to 800 Hz. Remember that when cutting you should have your Q pretty narrow because you are trying to repair your recording, and cutting too broadly from the frequency spectrum will severely compromise the natural sound of the vocal.

4. In Your Face Presence of the 5 kHz

If your singer doesn’t seem to be cutting through the mix, he might need to be presented to 5Khz. It will push the track a little more to the front and give the singer a much-needed presence.

5. Sibilance Around the 7 kHz

Some people have more sibilance than others. The s’ sounds have much more energy than other consonants. If your singer has an excess of S’s you can try cutting around 7 kHz. It will make the S’s less pronounced and won’t make them jump out too much. Better yet, inserting a de-esser or a compressor that only compresses the ‘s’ area can work even better. Male sibilance is typically 3-7k Hz and female sibilance is typically 5-9k Hz so there needs to be some experimentation to find that annoying ‘s’ sound.
